Material Overview
Metals
About Ceramics
Metal Powder
Metal powders for 3D printing are widely used in the aerospace field in addition to the manufacture of
vehicle electronic material parts. High-intensity and purity, Our Metal Powder delivers high-purity and high-quality
technology. The 3DMETAL-M1 series including aluminum, titanium, and copper, delivers the best performance.
Material 01
| Metal Slurry | |
| Solids loading [vol%] | 45 ~ 54 |
| Viscosity 1 [Pa·s] | 1.8 ~ 15 |
| Sintered Metal | |
| Theoretical density [g/cm³] | 6.05 |
| Relative density [%] | 99.5 |
| Porosity [%] | 0.5 |
| 3 point bending strength [MPa] | 600 ~ 950 |
Materials Under Development ···
*¹ Value was determined at a constant shear-rate of 50 s-1 at 26°C
| Alumina Slurry | Si₃N₄ | ATZ | Y₂O₃ |
| Solids loading [vol%] | 40 ~ 50 | 45 ~ 54 | 45 ~ 54 |
| Viscosity 1 [Pa·s] | 2 ~ 50 | 1.8 ~ 15 | 1.8 ~ 15 |
| Sintered Alumina | Si₃N₄ | ATZ | Y₂O₃ |
| Theoretical density [g/cm³] | 3.17 | 5.0 ~ 5.6 | 5.01 |
| Relative density [%] | 98.5 ≤ | 99.0 ≤ | 99.2 ≤ |
| Porosity [%] | 0.2 ~ 1 | 0.2 ~ 1 | 1 ~ 0.2 |
| 3 point bending strength [MPa] | 600 ~ 780 | 1,100 ~ 1,800 | 120 ~ 180 |
